CONSTANT TEMP BATH, 115V, 50/60 HZ (C003B-360066)

Wide temperature range 20°C to 150°C Easy temperature setting Insulated for precise solid-state temperature control Multiple safety features Ideal for temperature control of other instruments which must be viewed while immersed in a constant temperature bath. The top cover contains seven round holes 51 mm (2") in diameter for insertion of viscometers. Each unit maintains accurate temperature control of 0.01°C within the range of 20°C to 100°C and 0.03°C above 100°C, providing the temperature sensitivity required by ASTM D 445 for kinematic viscosity measurements. Two electric heating elements inside the bath rapidly heat the medium to any desired temperature within the range. A cooling coil, when connected to tap water or a cooling system, permits operation below or slightly above ambient temperature. A selector switch facilitates rapid setting of ten temperatures for kinematic viscosity determinations: 20, 25, 30, 40, 50, 60, 80, 100, 135 and 150°C. The “variable” setting allows any temperature within the operating range to be obtained. A solid-state control circuit provides proportional control of temperature. The sensing element for the control circuit is a stainless steel-encased thermistor. A motor driven stirrer ensures a uniform temperature throughout the bath. The entire electrical control system is located in a convenient drawer, mounted on ball-bearing glides for easy access. The bath chamber is a cylindrical clear glass vessel. A stainless steel baffle provides a plain, reflective background to aid in viewing. Two fluorescent lamps illuminate the interior of the vessel. A second thermistor in the bath senses any over-temperature fault condition and removes power from the bath until the over- temperature limit circuit is reset. A liquid-level control prevents bath heating until a safe liquid level is attained. All wetted parts of the unit are made of stainless steel or glass. The frame is heavy aluminum and coated with a corrosion-resistant epoxy finish; the top cover is insulated stainless steel. Dimensions (W x D x H, mm): 438 x 464 x 584 (17.25 x 23"). Shipping weight: 57 kg (126 lbs). CT-1000HT (9726A27 and A29) Maximum Temperature: 200°C Temperatures from 150 to 200°C can be controlled to 0.03°C which is more precise than required by ASTM D 445 for high temperature viscometry. Otherwise identical to the CT-1000.

UPC:

41103700

Condition:

New

Weight:

1.00 Ounces

HazmatClass:

No

Quantity:

1

Unit of Measurement:

EA

WeightUOM:

LB

MPN:

9726-A27
