SDC Benchtop Temperature Controller, 120V, C, J-Type

Product Highlights Affordable and compact Compatible with a wide range of heaters andapplications Easy-to-use programmable digital controller, self contained, plug and play design Specifications Small Unit Size: 5.5 in L x 4.25 in W x 1.75 in H (140 mm L x 108 mm W x 45 mm H) On-Off control Temperature Control Range: 32-999°F (0- 600°C): Accuracy: +/- 0.6% of Span, +/- 1 Digit J-type or K-type Thermocouple Sensor: 5-foot (1.5 m) factory installed 120 VAC or 240 VAC power input Relay output rated for 10A @ 240 VAC In the case of probe failure, heating can be selected on,off or periodical running Upper and lower limits of the setpoint can be adjusted Set-point value can be adjusted by using single key Hysteresis adjustable between 1 and 20 degrees Exposure Temperature: 32-122°F (0-50°C): 80% humidity non-condensing 5-foot (1.5 m) input power cord: 120VAC unit = NEMA 5-15 plug or 240VAC unit = NEMA 6-15 plug 5-foot (1.5 m) output power cord: 120VAC unit = NEMA 5-15R receptacle or 240VAC unit = NEMA 6-15R receptacle

UPC:

41102404

Condition:

New

Weight:

1.00 Ounces

HazmatClass:

No

Quantity:

1

Unit of Measurement:

EA

WeightUOM:

LB

MPN:

SDC120JC-A
